Key Technical Specifications & Features:
- Power Output: 300W RMS into 2 Ohms, 210W RMS into 4 Ohms
- Channels: 6, each with independent level, monitor, effects, and 2-band EQ (low/high).
- Master Section: 9-band graphic EQ, master level, monitor send, and effects return.
- Protection: DDT (“Distortion Detection Technique”) compression to minimize clipping.
- Effects: Built-in spring-type reverb with master and monitor control.
- Inputs/Outputs: Balanced Low-Z (XLR) and Unbalanced High-Z (1/4”) per channel.
- Weight/Dimensions: ~40 lbs.
- Era: Produced in the 1980s in the USA.
The amplifier section utilizes eight TO-3 power devices on a large heatsink.
